Intumescent Pipe Wraps

Protecta FR Pipe Wrap is designed to maintain the fire resistance of fire separating walls and floors when these are breached by plastic pipes, conduits or metal pipes with continuous combustible insulation. It may be used in drywalls, masonry or concrete walls and floors.

Each pipe wrap consists of a graphite-based reactive intumescent strip which reacts to heat and closes the opening left by the softening plastic pipe or pipe insulation in a fire. It can be installed completely around the pipes or insulation and secured with the self adhesive tab. The annular space around the pipe wrap is to be sealed with Protecta EX Mortar or FR Board.

No detailed specifications are available for this product.

There are no downloads for this product.

Code Description Pipe (mm) Size Fire Resistance Price
21062 Intumescent Pipe Wrap - 55mm - FR 4 Hour For Plastic Pipes & Conduits < ?55mm 55mm Up To 4 Hours
21065 Intumescent Wraps - 82mm For Plastic Pipes & Conduits < ?82mm 82mm Up To 4 Hours
21066 Intumescent Pipe Wrap - 110mm - FR 4 Hour For Plastic Pipes & Conduits < ?110mm 110mm Up To 4 Hours
21068 Intumescent Pipe Wrap - 125mm - FR 4 Hour For Plastic Pipes < ?125mm 125mm Up To 4 Hours
21069 Intumescent Pipe Wrap - 160mm - FR 4 Hour For Plastic Pipes < ?160mm 160mm Up To 4 Hours
21070 Intumescent Pipe Wrap - 200mm FR 3 Hour For Plastic Pipes < ?200mm 200mm Up To 3 Hours
21071 Intumescent Pipe Wrap - 250mm - FR 3 Hour For Plastic Pipes < ?250mm 250mm Up To 3 Hours
21072 Intumescent Pipe Wrap - 315mm - FR 2 Hour For Plastic Pipes < ?315mm 315mm Up To 2 Hours
21320 FR Pipe Wrap 50mm X 25mtr Fire Stopping 50mm x 25mtr Up To 4 Hours
21321 FR Pipe Wrap 75mm X 25mtr Fire Stopping 75mm x 25mtr Up To 4 Hours
Please login to see prices..
